Easenet Outdoor Copper UTP Cat 6 Cable — 305m Reel
The Easenet Outdoor Copper UTP Cat 6 Cable is a weatherproof structured cabling solution designed for external horizontal runs, inter-building links, and exposed installation environments. It meets the ANSI/TIA-568.2-D and ISO/IEC 11801 Cat 6 (Class E) performance standards at 250 MHz, while its UV-stabilised outdoor jacket protects the cable against the environmental conditions that would degrade a standard indoor Cat 6 cable within months of external exposure.
The distinction between indoor and outdoor Cat 6 cable is a critical specification decision. Standard PVC indoor jackets are not formulated to resist UV radiation, moisture ingress, or temperature cycling across wide seasonal ranges. Consequently, deploying indoor cable in external or semi-exposed environments leads to jacket cracking, moisture penetration into the cable core, and progressive signal degradation that is difficult to diagnose after installation. The Easenet Outdoor Cat 6 cable addresses this directly through its outdoor-rated jacket compound and solid bare copper conductor construction.
Performance and Bandwidth
The Easenet Outdoor Copper UTP Cat 6 cable is rated to 250 MHz, supporting Gigabit Ethernet (1000BASE-T) across the full 100-metre horizontal channel. Additionally, it supports 10GBASE-T over shorter runs of approximately 55 metres within a standard compliant channel — providing forward compatibility with 10G switching infrastructure without requiring outdoor cable replacement.
Electrical performance parameters including NEXT, PS-NEXT, and ACR-F are controlled to ANSI/TIA-568.2-D Cat 6 limits across the operating temperature range. This is an important distinction from indoor Cat 6 cable — outdoor cables must maintain these parameters across a wider temperature envelope, as electrical characteristics of copper cable shift with temperature. The Easenet Outdoor Cat 6 is formulated to remain within Cat 6 performance limits across its rated operating temperature range.
Cable Construction
The Easenet Outdoor Cat 6 cable uses four twisted pairs of solid bare copper conductors at 23 AWG. Solid construction is specified for horizontal fixed runs — it provides lower attenuation per metre than stranded cable and is the correct construction type for permanent installation. Bare copper, rather than copper-clad steel (CCS) or copper-clad aluminium (CCA), ensures consistent electrical performance and compatibility with standard crimp and punch-down termination tooling. CCA and CCS conductors are not compliant with TIA-568.2-D and can cause termination failures with standard keystone jacks and patch panels.
An internal spline separator isolates the four pairs within the jacket, reducing crosstalk in high-density bundle environments. The outer jacket is an outdoor-rated UV-stabilised PVC or polyethylene compound, formulated to resist:
- UV radiation — Prevents jacket embrittlement and cracking under prolonged sun exposure
- Moisture — Resists water ingress along the cable run and at termination points
- Temperature cycling — Maintains flexibility and jacket integrity across seasonal temperature extremes
- Ozone and atmospheric pollutants — Relevant in urban and industrial installation environments
The jacket is typically black — the standard colour for UV-stabilised outdoor cable compounds, as carbon black provides effective UV absorption.
Outdoor Installation Suitability
The Easenet Outdoor Cat 6 is suited to the following external and semi-exposed installation scenarios:
Aerial runs — Where cable is suspended between buildings or structures on a catenary support wire, outdoor-rated jacket construction handles the mechanical stress of wind loading and temperature-driven expansion and contraction cycles that occur on exposed aerial spans.
External wall and façade routing — Surface-mounted runs on external building walls are exposed to direct UV, rain, and temperature variation. The UV-stabilised jacket maintains integrity in these conditions where standard PVC would degrade.
Underground conduit — When routed through buried conduit, the outdoor jacket provides an additional layer of moisture protection. For direct burial without conduit, a gel-filled or armoured variant should be specified instead — the Easenet Outdoor Cat 6 in standard jacket form is not rated for direct burial.
Roof voids and unheated spaces — Roof voids, car park structures, and unheated industrial spaces experience temperature extremes and condensation cycling that exceed the tolerance of standard indoor cable jacket compounds.
Termination Considerations
Outdoor Cat 6 cable uses solid 23 AWG conductors, which terminate correctly into standard Cat 6 keystone jacks, patch panels, and IDC punch-down blocks using standard 110-style tooling. No specialist termination equipment is required beyond what is used for indoor Cat 6.
However, termination points at the transition between outdoor and indoor environments require weatherproofing attention. Unprotected RJ45 field plugs and keystone jacks exposed to moisture will corrode and fail. Terminations in external locations should use weatherproof keystone enclosures, IP65-rated surface mount boxes, or gel-filled weatherproof RJ45 plugs. Where the cable transitions from outdoor to indoor at a building entry point, the entry penetration should be sealed to prevent moisture tracking along the cable into the internal installation.
Supported Applications
The Easenet Outdoor Copper UTP Cat 6 cable supports the following applications across a compliant 100-metre channel:
- 1000BASE-T — Gigabit Ethernet (IEEE 802.3ab) for inter-building links and external AP connections
- 100BASE-TX — Fast Ethernet
- 10GBASE-T — 10 Gigabit Ethernet over shorter runs (~55m channel)
- PoE / PoE+ — Up to 30W (IEEE 802.3at) for external PoE cameras and access points
- PoE++ — Up to 90W (IEEE 802.3bt) for high-power external devices
- Outdoor IP Surveillance — External IP camera cabling to NVR or PoE switch infrastructure
- Wi-Fi Access Points — External PoE-powered 802.11ac/ax WAP backhaul cabling
- Inter-Building Links — Campus and multi-building network connections via external aerial or conduit routes
- Access Control — External PoE-powered door controllers, video intercoms, and card readers
Ideal Users
- Network Infrastructure Contractors on Mixed Indoor/Outdoor Projects — Building-to-building links, external access point cabling, and perimeter camera runs are routine elements of commercial network and security projects. The Easenet Outdoor Cat 6 handles these external segments within the same Cat 6 specification framework as the internal structured cabling, simplifying channel design and certification.
- Security and CCTV System Installers — External IP cameras on PoE switches require outdoor-rated cable from the camera head back to the internal network closet or NVR location. Deploying indoor Cat 6 on these runs is a known failure mode that generates callback work within 12–24 months in exposed climates. The Easenet Outdoor Cat 6 eliminates this risk.
- Education and Healthcare Campus Facilities Teams — Multi-building campuses require inter-building data links and external wireless coverage. Outdoor Cat 6 cabling through buried conduit or aerial pathways between buildings provides Gigabit connectivity without the cost of fibre, while PoE++ support accommodates high-power outdoor access points and IP camera systems on the same cable.
- Hospitality and Retail Property Operators — Hotels, resorts, retail parks, and outdoor dining venues require external Wi-Fi coverage and IP camera infrastructure in environments exposed to weather. Outdoor Cat 6 cabling to external access points and camera positions supports these deployments reliably over multi-year installation lifespans.
- Industrial and Logistics Site Operators — Warehouses, distribution centres, and manufacturing facilities have roof voids, loading dock areas, and external yard spaces that fall outside the temperature and moisture tolerance of indoor cable. The Easenet Outdoor Cat 6 handles these semi-exposed internal and external areas within the same cable specification.
Cable Specifications
| Attribute | Detail |
|---|---|
| Category | Cat 6 (Class E) |
| Standard | ANSI/TIA-568.2-D / ISO/IEC 11801 |
| Conductor | 23 AWG Solid Bare Copper |
| Pairs | 4 Twisted Pairs |
| Shield Type | Unshielded (U/UTP) |
| Pair Separator | Internal Spline (cross-filler) |
Performance Specifications
| Attribute | Detail |
|---|---|
| Rated Bandwidth | 250 MHz |
| Max Channel Length | 100 metres |
| 10GBASE-T Support | Up to ~55m (standard channel) |
| Impedance | 100Ω (±15Ω) |
| NEXT (at 100 MHz) | ≥44.3 dB |
| PS-NEXT (at 100 MHz) | ≥42.3 dB |
| Attenuation (at 100 MHz) | ≤19.8 dB/100m |
Physical Specifications
| Attribute | Detail |
|---|---|
| Jacket Material | UV-Stabilised Outdoor PVC or PE |
| Jacket Colour | Black |
| Outer Diameter | Approx. 6.0–6.5mm |
| Reel Length | 305m (1,000 ft) |
| Packaging | Pull-box reel |
| Operating Temperature | -40°C to +70°C |
| Installation Temperature | -10°C to +50°C |
Environmental Ratings
| Attribute | Detail |
|---|---|
| UV Resistance | Yes — UV-stabilised jacket compound |
| Moisture Resistance | Yes — outdoor jacket formulation |
| Direct Burial | Not rated — conduit required for underground runs |
| Temperature Range | -40°C to +70°C operating |
Installation Parameters
| Attribute | Detail |
|---|---|
| Maximum Pull Tension | 110N |
| Minimum Bend Radius (installation) | 25mm |
| Minimum Bend Radius (installed) | 25mm |
| External Termination | IP65-rated enclosures or weatherproof RJ45 required |
| Building Entry Sealing | Penetration must be sealed to prevent moisture tracking |
| Recommended Termination | Cat 6 Keystone Jacks / Patch Panels (110-style IDC) |
Certifications
| Certification | Detail |
|---|---|
| TIA | ANSI/TIA-568.2-D Cat 6 |
| ISO/IEC | 11801 Class E |
| IEEE | 802.3ab (1000BASE-T), 802.3bt (PoE++) |
| Environmental | RoHS Compliant |
