MikroTik L009UiGS-RM Wired Router, 2.5 Gigabit Ethernet, Rackmount
Businesses building out a server room or network cabinet will find a solid fit in the MikroTik L009UiGS-RM, a wired-only router purpose-built for rack-mounted deployments. At its core sits a dual-core IPQ-5018 CPU clocked at 800MHz with 512MB of RAM, giving it enough headroom to handle demanding RouterOS configurations without breaking a sweat. Connectivity is generous: 8 Gigabit Ethernet ports (one with PoE-out for powering downstream access points or cameras) plus a 2.5G-capable SFP port for a fast fiber or copper uplink. A USB 3.0 port and RJ45 serial console round out the physical interfaces for storage expansion and low-level troubleshooting. It ships running RouterOS v7 with a Level 5 license already activated, so there’s no separate software purchase — just rack it, cable it, and configure. The included rackmount kit, screws, and adhesive pads make for a tidy, professional install in any standard network cabinet, and MikroTik backs the unit with a minimum of 5 years of free software updates.
Key Features
- Dual-core IPQ-5018 CPU at 800MHz with 512MB RAM for strong routing and processing performance
- 8x Gigabit Ethernet ports, including 1 with PoE-out for powering connected devices
- 2.5G-capable SFP port for high-speed fiber or copper uplink connectivity
- Rack-mountable design, shipping with a dedicated rackmount kit for clean installation in network cabinets
- RouterOS v7 with Level 5 license included, ready to use out of the box with 5+ years of free updates
Technical Specifications
| Specification | Details |
|---|---|
| Model | L009UiGS-RM |
| Architecture | ARM 32-bit |
| CPU | IPQ-5018, dual-core, 800 MHz |
| RAM | 512 MB |
| Storage | 128 MB NAND |
| Operating System | RouterOS v7, Level 5 license |
| Ethernet Ports | 8x 10/100/1000 Gigabit Ethernet, 1 with PoE-out |
| SFP Port | 1x SFP (2.5G supported) |
| USB Port | 1x USB 3.0 Type-A, 1.5A max current |
| Serial Console | RJ45 |
| Power Input | 24-56V DC jack, PoE-in (802.3af/at) |
| Max Power Consumption | 40W (8W without attachments) |
| PoE-out | Passive PoE, up to 1A total output |
| Cooling | Passive (fanless) |
| Certifications | CE, EAC, RoHS, IP20 |
| MTBF | Approximately 200,000 hours at 25°C |
| Operating Temperature | -40°C to 70°C |
| Included Accessories | 24V 1.5A power adapter, rackmount kit K-79, K-55 screw kit, K-87, adhesive pads |
Best Suited For
- Server rooms and structured cabling closets where a clean, rack-mounted router is preferred over a desktop unit
- ISPs and businesses needing extensive Gigabit Ethernet ports paired with a fast SFP uplink for fiber connectivity
- Network administrators who want PoE-out built in, saving the cost of a separate injector for access points or cameras
