Ugreen NW102 Network Adapter (UG- 20159)

UGREEN NW102 USB Network Adapter (UG-20159)

Ethernet to USB Conversion

The UGREEN NW102 transforms USB connectivity to RJ45 Ethernet, enabling network access for devices lacking built-in Ethernet ports. This compact adapter processes data transfers up to 100 Mbps, bridging the gap between USB devices and traditional wired networks.

Plug-and-Play Design

The NW102 simplifies network connectivity through:

• Driver-free installation on major operating systems
• LED indicators for connection and activity status
• Compact form factor minimizing desk footprint
• Integrated USB cable for flexible positioning
• Tool-free setup process

Technical Implementation

The adapter employs several key technologies:

• RTL8152B chipset for reliable data processing
• Full-duplex communication for bidirectional data
• Auto-negotiation for optimal connection speed
• Built-in error correction algorithms
• Wake-on-LAN support for remote power management

Best Suited For

• Ultrabook users requiring wired connectivity
  • Adds Ethernet capability to slim devices
  • Compatible with standard USB ports
• Remote workers needing backup connections
  • Provides stable wired network alternative
  • Supports video conferencing requirements
• Legacy system users
  • Enables network access for older devices
  • Maintains compatibility with 10/100 networks

Technical Specifications

Physical Properties

• Length: 6.5 cm (adapter body)
• Cable length: 12 cm
• Interface: USB to RJ45
• Weight: 28g
• Color: Black

Performance Features

• Data transfer: Up to 100 Mbps
• USB version: 2.0
• Power consumption: 5V/100mA
• Network standards: 10BASE-T/100BASE-TX

Compatibility

• Windows 7/8/10/11
• macOS 10.6 and later
• Chrome OS
• Linux kernel 2.6.25 and later

Standards Support

• IEEE 802.3
• IEEE 802.3u
• USB 2.0 specification
• IPv4/IPv6 protocols

The UGREEN NW102 serves as a practical solution for adding Ethernet connectivity to USB-equipped devices, offering reliable performance in a compact format. The UG-20159 maintains consistent functionality across various operating systems while providing essential networking features for everyday use.
