Lenovo ThinkCentre M70t Gen 5 Tower, Core i5 14400 (14th Gen), 8GB DDR5, 512GB SSD
The Lenovo ThinkCentre M70t Gen 5 Tower brings dependable business performance and maximum expandability to a full tower form factor, powered by the Intel Core i5-14400 processor, a 10-core (6P + 4E), 16-thread chip with P-core Turbo speeds up to 4.7 GHz and a 20MB Intel Smart Cache. Built on the Intel Q670 chipset, it comes with 8GB of DDR5-4800 memory and a 512GB PCIe 4.0 NVMe SSD with Opal 2.0 hardware encryption, alongside an empty second DIMM slot and support for up to three total drives. Integrated Intel UHD Graphics 730 handle everyday business visual tasks. Unlike the compact SFF variant, the M70t offers full-height PCIe slots (one x16, one x1) for greater card compatibility, housed in a 13.6-litre tower chassis weighing 5.9 kg. Connectivity is extensive, including a USB-C port with 15W charging, four front USB-A ports, four rear USB 2.0 ports, HDMI 2.1, and DisplayPort 1.4a. Security features include discrete TPM 2.0 (TCG and FIPS 140-2 certified), a Smart Cable Clip, and Kensington lock support, backed by MIL-STD-810H durability testing and TCO Certified generation 9 sustainability credentials. This configuration ships with no operating system and includes a USB keyboard and mouse.
Key Features
- Intel Core i5-14400 processor with 10 cores, 16 threads, and P-core Turbo speeds up to 4.7 GHz
- 512GB PCIe 4.0 NVMe SSD with Opal 2.0 encryption, plus support for up to three total drives
- Full-height PCIe expansion slots, offering greater card compatibility than compact SFF alternatives
- Discrete TPM 2.0, TCG and FIPS 140-2 certified, for enterprise-grade security
- Smart Cable Clip and Kensington lock support, adding physical security for shared or public-facing spaces
Technical Specifications
| Specification | Details |
|---|---|
| Processor | Intel Core i5-14400, 10 cores (6P+4E), 16 threads, up to 4.7 GHz Turbo, 20MB Smart Cache |
| Chipset | Intel Q670 |
| Operating System | None (No OS) |
| Graphics | Integrated Intel UHD Graphics 730 |
| Memory | 8GB DDR5-4800 (1x UDIMM), dual-channel capable, expandable to 64GB |
| Storage | 512GB M.2 2280 PCIe 4.0 x4 NVMe SSD with Opal 2.0 encryption; supports up to 1x 3.5″ HDD (2TB), 1x 2.5″ HDD, 1x M.2 SSD (2TB) |
| Expansion Slots | 1x PCIe 3.0 x16 (full-height), 1x PCIe 3.0 x1 (full-height), 2x M.2 (1 WLAN, 1 SSD) |
| Form Factor | Tower (13.6L) |
| Chassis Color | Black |
| Keyboard/Mouse | USB Traditional Keyboard, USB Calliope Mouse |
| Ports (Front) | 1x USB-C (5Gbps, 15W charging), 4x USB-A (5Gbps), 1x headphone/mic combo, 1x microphone jack |
| Ports (Rear) | 4x USB-A (2.0), 1x HDMI 2.1, 1x DisplayPort 1.4a, 1x Ethernet (RJ-45) |
| Wireless | Intel Wi-Fi 6E AX211 (2×2, vPro) and Bluetooth 5.3 |
| Network | Integrated 100/1000M Ethernet |
| Security | Discrete TPM 2.0 (TCG, FIPS 140-2 certified), Smart Cable Clip, Kensington Security Slot, padlock loop |
| Manageability | Non-vPro |
| Power Supply | 260W, 90% efficiency |
| Dimensions | 145 x 296 x 346 mm |
| Weight | Approximately 5.9 kg (13.0 lb) |
| Certifications | GREENGUARD, TCO Certified generation 9, RoHS compliant, MIL-STD-810H tested |
| Warranty | 1-year (3-year Courier/Carry-in upgrade available) |
Best Suited For
- Businesses needing full-height PCIe card compatibility, such as discrete graphics or specialized expansion cards
- Organizations handling sensitive data, thanks to FIPS 140-2 certified TPM and Opal 2.0 SSD encryption
- Shared or public-facing office environments, benefiting from the Smart Cable Clip and physical lock support
